Specification

Number Of Computer Controlled

2

Selection Method

Push Button/Hot Key

LEDs

HUB Switch LED ( Green)

PC Host LED (RED)

Auto Switch & Auto Scan LED (Green)

Compliant with USB Version

USB1.0 / USB1.1 / USB2.0

Compliant with HID Version

USB HID 1.11

PC Connectors

Video

2 x HDB-15 male

USB

2 x USB Type B female

Microphone

2 x Audio Jack Female (Pink)

Speaker

2 x Audio Jack Female (Green)

Console port

Video

1 x HDB-15 female

Keyboard/Mouse

2 x USB Type A female

Microphone

1 x Audio Jack Female (Pink)

Speaker

1 x Audio Jack Female (Green)

USB Downstream ports

2 x USB Type A female

Auto-Scan Interval

5,10,15,20 sec

DDC, DDC2 monitor

Yes(Max.Resolution:1920x1200 @60Hz)

Operating system supported

Win 98/98SE/ME/2000/XP/Vista/7,

Mac OS9/X, Linux, Sun Micro OS

Cables Included

2 sets of USB, VGA and audio cable

Cable Length

1.8M

Power

By External Adaptor

Output Voltage

5V

Output Current

2A

Hot Pluggable

Yes

Dimensions (LxWxH)

170 x 82 x 44 mm

Unit Weight

685g
