Specification
|
|
Number Of Computers Controlled
|
4
|
|
Selection Method
|
Push Button and Hot-Key (PS/2 and/or USB Keyboard)
|
|
LEDs
|
Red for PC Selection
Green for PC On-Line ready
|
|
PC Connectors
|
Video
|
1 x HDB-15 male ( PS/2 & USB signal combined )
|
|
Console Ports
|
Keyboard
|
1 x 6 pin mini-DIN female
|
|
Mouse
|
1 x 6 pin mini-DIN female
|
|
Video
|
1 x HDB-15 female
|
|
Keyboard
|
1 x USB – A type female
|
|
Mouse
|
1 x USB – A type female
|
|
Auto-Scan Interval
|
From 5 to 250 Seconds
|
|
DDC, DDC2 monitor
|
Yes (Max. Resolution: 2048x1536)@85Hz
|
|
Hot Swappable
|
Yes
|
|
Operating systems supported
|
Windows 98SE/ME/2000/XP/Vista/2003 Server, Linux
Mac OS9/OSX and Sun Micro System
|
|
Device driver
|
No Need
|
|
Power
|
By PS/2 and/or USB or Power Adaptor (Optional)
|
|
Cable Length
|
6 feet (1.80 Meter)
|
|
Dimensions (L X W X H)
|
21.5 x 8.8 x 4.5 cm (5.5 X 3 X 1.7 inches)
|
|
Unit Weight
|
650 g
|
|
Housing material
|
Metal
|
|
Operating Temperature
|
32~ 122°F (0~ 50°C )
|
|
Humidity
|
0%~80%RH
|
