OCT offers an ideal enterprise 8-port KVM switches solution for company server room or testing facilities. OCT Combo Free 8-port USB & PS/2 KVM switches feature the patented design of the availability of USB & PS/2 interface connection, user friendly OSD utility, Daisy chain function, and the flexibility of Firmware-Upgradable function.

OCT Combo Free 8-port USB & PS/2 KVM switches is the reliable and convenient solution for enterprise with USB connection demand.

• Console your Keyboard/Mouse via PS/2 and/or USB at will.
• Connect computers via PS/2 and/or USB at will.
• Supports Windows, Linux, Mac OS9/OSX, Sun Microsystems.
• On-Screen-Display (OSD) & Cascade Chain functions.
• OSD is intuitive menus driven for quick and efficient navigation.
• Supports Daisy chain with 3 level cascades: up to 3 levels; control up to 64/256/4096 PCs, from a single console; cascaded units don’t need special configuration.
• Emulates PS/2 or USB keyboard on each PC to allow your computers to boot normally without a keyboard error.
• Supports hot-pluggable. All devices connected to the KVM can be added or removed at any time, without shutting the unit down.
• Supports 3 types of switching:
  . Hardware Push Button
  . Hot-Keys on PS/2 and/or USB of keyboard,
  . Menu driven OSD (On Screen Display)
• Supports Auto-Scan function to switch video inputs automatically among computers in preset intervals sequentially by OSD menu driven.
• Supports LED display for PC and/or server status monitoring.
• Supports VGA resolutions up to 2048 x 1536
• Supports Beeper during Switching enabled.
• Fully compliant with the USB 1.1/ 2.0 specification.
• Rack Mountable in 19” system tack (1U).
• KVM firmware is upgradable via on-board mini-USB download connector and external mini-programmer.

Patent No. TW M 284961, DE 20 2006 002 295.3, ZL 2005 20132700.2
