8-port VGA Switch with Audio (VS-181AR)

Model ：VS-181AR

8-port VGA Switch with Audio (Remote Control)

Similar products

Number Of Computers Controlled		8
Number Of Monitors Displayed		1
Selection Methods		Front Push Button or IR Remote Control
LED indicators		PC selection (Red)
		PC online (Green)
PC connector Ports	Video	8 x HDB-15 female
	Speaker	8 x stereo speaker jack
Console Ports	Video	1 x HDB-15 female
	Speaker	1 x stereo speaker jack
DDC, DDC2B		Max. resolution: 2048 x 1536@85Hz
Maximum Bandwidth		450 MHz
Operation System Supported		Windows 98E/ME/2000/XP/Visa/7/2003 server, Linux, Mac OS9/OSX and Sun Microsystems
Power		By external power adaptor DC 5V
Dimension (L x W x H)		21 x 8.5 x 4.5cm (8.5 x 3.5 x 1.9 inch)
Unit Weight		800 g
Housing Material		Metal
Operation Temperature		32 ~ 122℉ (0~50℃)
Humidity		0% ~ 80% RH
