Specification
|
|
Number Of Computer Controlled
|
4
|
|
Selection Method
|
Push Button/Hot Key
|
|
LEDs
|
HUB Switch LED ( Green)
|
|
PC Host LED (RED)
|
|
Auto Switch & Auto Scan LED (Green)
|
|
Compliant with USB Version
|
USB1.0 / USB1.1 / USB2.0
|
|
Compliant with HID Version
|
USB HID 1.11
|
|
PC Connectors
|
Video
|
4 x HDB-15 male
|
|
USB
|
4 x USB Type B female
|
|
Microphone
|
4 x Audio Jack Female (Pink)
|
|
Speaker
|
4 x Audio Jack Female (Green)
|
|
Console port
|
Video
|
1 x HDB-15 female
|
|
Keyboard/Mouse
|
2 x USB Type A female
|
|
Microphone
|
1 x Audio Jack Female (Pink)
|
|
Speaker
|
1 x Audio Jack Female (Green)
|
|
USB Downstream ports
|
2 x USB Type A female
|
|
Auto-Scan Interval
|
5,10,15,20 sec
|
|
DDC, DDC2 monitor
|
Yes(Max.Resolution:1920x1200 @60Hz)
|
|
Operating system supported
|
Win 98/98SE/ME/2000/XP/Vista/7,
|
|
Mac OS9/X, Linux, Sun Micro OS
|
|
Cables Included
|
4 sets of USB, VGA and audio cable
|
|
Cable Length
|
1.8M
|
|
Power
|
By External Adaptor
|
|
Output Voltage
|
5V
|
|
Output Current
|
2A
|
|
Hot Pluggable
|
Yes
|
|
Dimensions (LxWxH)
|
200 x 82 x 44 mm
|
|
Unit Weight
|
900g
|
